Masi Bikes

BRUNELLO R10

BRUNELLO R10

$1,699.99 USD
$1,699.99 USD $1,699.99 USD
Sale Sold out
Shipping calculated at checkout.

42331

With an aluminum gravel frame, carbon fork, and new geometry, the Brunello is dialed for road and gravel alike. Its dropped chainstay, room for 45c tires, all-road geo, and 2X drivetrain, the Brunello R10 is ready for you to choose your own adventure.
Color
Size
View full details
Two cyclists ride along a gravel path beside train tracks in a forested area. They wear helmets and jackets, with sunlight filtering through the trees. A yellow train car is visible on the left.

FEATURES

  • Butted, formed, and smooth welded gravel-specific aluminum frame
  • Full-carbon fork
  • 12mm thru-axles
  • microSHIFT R10 2X 10-speed drivetrain
  • 650b or 700c compatible
  • 700x45c tire clearance
  • Dropper post compatible
  • New, more aggressive geometry

SPECIFICATIONS

FRAMESET
FrameBrunello gravel | Smooth welded double-butted aluminum | 1.125 - 1.5" integrated head tube | BB86 bottom bracket | Flat-mount disc brake | Replaceable derailleur hanger | Internal dropper post compatible | 12 x 142mm thru-axle
ForkBrunello gravel | MC-9 carbon construction | Carbon 1.125 - 1.5" tapered steer tube | Flat-mount disc | Fender mounts | 12 x 100mm thru-axle
ColorsMatte Cool Grey
DRIVETRAIN
CranksBrev. M All-Road 9/10s | 46/30T chainrings | 47-51cm : 170mm, 54-56cm : 172.5mm, 58-60cm : 175mm
Pedals--
ChainKMC X10
Bottom BracketBB86 for 24mm spindle
Front DerailleurmicroSHIFT FD-R712 | Band-type | ϕ 31.8mm clamp
Rear DerailleurmicroSHIFT RD-R43M 10s
Derailleur ShiftermicroSHIFT ADVENT X
Freewheel/CassetteSunrace CSMS1 | 10-spd | 11-34T
WHEELS
TiresHutchinson Overide | 700x38c | Bi-compound | Folding
Wheels/RimsBrev M. 700c Performance Gravel Disc | Depth: 23mm, Width (internal): 21mm | 28H | Double wall | Tubeless compatible
HubsBrev M. Disc | Sealed bearings | Front: 12 x 100mm thru-axle, Rear: 12 x 142mm thru-axle | 6-bolt | 28H
BRAKING SYSTEM
BrakesRever MCX2 disc | Flat mount | Dual piston | 6-bolt rotors, 160mm
Brake LeversmicroSHIFT SB-R502
OTHER COMPONENTS
Grips/TapeMasi Gripper Silicone Gel
HandlebarBrev M. alloy all-road bend | ϕ 31.8mm | 120mm drop | 75mm reach | 47cm: 40cm, 51-56cm: 42cm, 58-60cm: 44cm
StemBrev M. Gravel Variable Rise | 3D forged alloy | -6/-12° drop | 47cm: 90mm, 51-54cm: 100mm, 56-58cm: 110mm, 60cm: 120mm
HeadsetFSA 42E 1.5" tapered
SaddleMasi Gravel Performance
Seat PostBrev M. Alloy | ϕ 27.2mm x 330mm | 5mm offset
Seat ClampAlloy | ϕ 31.8mm

GEOMETRY

SIZEXSSMLXLXXL
A. Top Tube (Effective)541mm (21.3")549mm (21.6")564mm (22.2")574mm (22.6")581mm (22.9")589mm (23.2")
B. Seat Tube (C-T)440mm (17.3")470mm (18.5")500mm (19.7")520mm (20.5")540mm (21.3")570mm (22.4")
C. Stack Height551mm (21.7")559mm (22")580mm (22.8")594mm (23.4")610mm (24")629mm (24.8")
D. Reach388mm (15.3")394mm (15.5")399mm (15.7")401mm (15.8")403mm (15.9")406mm (16")
E. Standover733mm (28.9")762mm (30")788mm (31")807mm (31.8")826mm (32.5")851mm (33.5")
F. Head Tube Length114.5mm (4.5")123mm (4.8")144mm (5.7")158.5mm (6.2")175mm (6.9")195.5mm (7.7")
G. Head Angle71.8°71.8°72.2°72.2°72.2°72.2°
H. Seat Angle74.5°74.5°74°73.7°73.7°73°
I. Wheel Base1011.1mm (39.8")1019mm (40.1")1026.4mm (40.4")1033.2mm (40.7")1040.2mm (41")1049.2mm (41.3")
J. Chainstay425mm (16.7")425mm (16.7")425mm (16.7")425mm (16.7")425mm (16.7")425mm (16.7")
K. BB Drop74mm (2.8")74mm (2.8")74mm (2.8")74mm (2.8")74mm (2.8")74mm (2.8")
L. Fork Offset45mm45mm45mm45mm45mm45mm
M. Stem Length90mm90mm100mm100mm110mm110mm
N. Bar Width400mm420mm420mm420mm440mm440mm
O. Crank Length165mm170mm172.5mm172.5mm175mm175mm
P. Wheel Size700700700700700700
